General Specifications

Solution:
Chipsets : BES2300Y
Bluetooth Standard : BT5.0
Support Profile : A2DP v1.3 AVRCP v1.5 HFP v1.6
Audio transmission format：SBC
RF Transmittion : 8dB
Transmission Range (Hz) 2402-2480mHz
Senstivity： ≤-85dBm
BT distance：Outdoor≥15M；Indoor≥20M
BT Pairing : PeopleLink Sonic OE12W
Microphone：
Microphone Unit : 4015
Directivity : Omnidirectional
S.P.L: -42dB
Impedance : 0.96KΩ
Frequency Response : 20Hz-20KHz
Operating voltage : 2V
Speaker driver:
Speaker diameter : 40±0.3mm
Impedance : 32Ω±15%
S.P.L : 120dB ± 3dB（1K，1mW IEC318)
Rated power : 10mW
Frequency Response : 20Hz-20KHz
Noise cancellation：
Microphone Unit : 6022
Directivity : Omnidirectional
Impedance： 2.2KΩ
S.P.L : -35± 1dB
dB reduct： 30 ± 2dB （MP Level）
Battery:
Li-battery Capability : 500mAH
Talking time : 23 hours BT
Playing time : 20 hours BT+ANC
Charging time :
• Full charging: 0.8-1 hours (Fasting charging function)
• Charging for 5 minutes, can support music playback
for 2-3 Hours.
Charging Mode : Type C
(Product has overvoltage protection）
Charger Current : 1.5A（The output current of the power
adapter needs ≥1.5A to ensure the charging time.）

Function : How to Use and Status
Turn on / off : 3S, Press and hold the
“dot“ button on the right headphone for 3S to
turn on/ off earphone
Bluetooth pairing : The headphone
automatically enters the Bluetooth pairing state
after power on
Microphone : In-built Unidirectional
microphone for seamless calling
Incoming call : 1click the “dot“ button on the
right earphone
End call : During the call，1 click the
“dot“ button on the right earphone
Reject call : 2S Long press 2 seconds on the
right headphone when calling
Music play/pause : 1click the “dot” button on
the right earphone when the music is playing,
and repeat the operation to pause
Volume up : 1click “+” button on right
headphone when the music is playing
Volume down : 1click “-” button on right
headphone when the music is playing
Previous track : 2S Press and hold 2 seconds
on right headphone when the music is playing
Next track : 2S Press and hold 2 seconds on the
left headphone when the music is playing
Turn on/off noise reduction : Move the noise
reduction button up to turn on the noise
reduction; move the noise reduction button
down to turn off the noise reduction;
Bluetooth disconnected : Turn off the
headphone
Automatic reconnection : After turning on the
headphone, automatically connects to the
mobile phone
Battery indicator : Support
Low Battery Remind : When the Battery is
lower than 20%, it will remind once a minute

–

Download Product Datasheet

https://www.peoplelinkvc.com/wp-content/uploads/2024/03/PeopleLink-Sonic-OE12W-Wireless-Headset-2024-4.pdf

–

Technical Data:
Rack Standard: Conforms to DIN 41494 or equivalent standard
Construction: Welded
Front Door: Lockable Toughened Glass Door,
Rear Door: Steel Vented Single.
Basic Frame: Steel
Equipment Mounting: DIN Standard 10mm Sq. Slots /
Direct M6 Tap
Mounting Angle: 19″ Mounting angles made of formed steel
Standard Finish: Powder Coated
Top and Bottom Cover: Welded to Frame, Vented and Field
Cable entry exit cut outs
Mounting Option: Castor wheels (Front 2 wheels with Break
and rear without break) Or Levelers or Base plinth
Standard Color: Black or Grey
Static Load: 250 kgs

Technical Data:
Rack Standard: Conforms to DIN 41494 or equivalent standard
Construction: Welded OR CKD (Knock Down)
Front Door: Lockable Toughened Glass Door,
Rear Door: Single Vented Steel Door.
Basic Frame: Steel
Equipment Mounting: DIN Standard 10mm Sq. Slots / Direct M6 Tap
Mounting Angle: 19″ Mounting angles made of formed steel
Standard Finish: Powder Coated
Top and Bottom Cover: Welded to Frame, Vented and Field Cable
entry exit cut outs
Mounting Option: Castor wheels (Front 2 wheels with Break and rear
without break) Or Levelers or Base plinth
Standard Color: Black or Grey
Static Load: 250 kgs

Technical Data:
Rack Standard: Conforms to DIN 41494 or equivalent standard
Construction: Welded OR CKD (Knock Down)
Front Door: Lockable Toughened Glass Door,
Rear Door: Vented Steel Single
Basic Frame: Steel
Equipment Mounting: DIN Standard 10mm Sq. Slots / Direct M6 Tap
Mounting Angle: 19″ Mounting angles made of formed steel
Standard Finish: Powder Coated
Top and Bottom Cover: Welded to Frame, Vented and Field Cable
entry exit cut outs
Mounting Option: Castor wheels (Front 2 wheels with Break and rear
without break) Or Levelers or Base plinth
Standard Color: Black or Grey
Static Load: 250 kgs

Technical Data:
Rack Standard: Conforms to DIN 41494 or equivalent standard
Construction: Welded OR CKD (Knock Down)
Front Door: Lockable Toughened Glass Door,
Rear Door: Steel Vented Single.
Basic Frame: Steel
Equipment Mounting: DIN Standard 10mm Sq. Slots / Direct M6 Tap
Mounting Angle: 19″ Mounting angles made of formed steel
Standard Finish: Powder Coated
Top and Bottom Cover: Welded to Frame, Vented and Field Cable
entry exit cut outs
Mounting Option: Castor wheels (Front 2 wheels with Break and rear
without break) Or Levelers or Base plinth
Standard Color: Black or Grey
Static Load: 350 kgs

Configuration for standard Racks is welded frame with 4 pillars of Multi Fold profile welded to top and
bottom panels. 2 Pair Depth rails to additionally support the Enclosure. Removable side panels partially
vented for better air circulation. Openings/Cut outs for field cable entry from Top & Bottom of the Rack.
Vented top cover with fan mounting provision, Front Glass or perforated Metal door with lock and key.
Back Vented, perforated or perforated Dual metal door with lock and key. Free Floor standing Design with
4 No. castor wheels 2 no’s with breaks and 2 no’s without breaks. Levelers or Plinth can be provided on
request.
Technical Data:
Rack Standard: Conforms to DIN 41494 or equivalent standard
Construction: Welded OR CKD (Knock Down)
Front Door: Lockable Toughened Glass Door,
Rear Door: Single Vented Steel
Basic Frame: Steel
Equipment Mounting: DIN Standard 10mm Sq. Slots / Direct M6 Tap
Mounting Angle: 19″ Mounting angles made of formed steel
Standard Finish: Powder Coated
Top and Bottom Cover: Welded to Frame, Vented and Field Cable
entry exit cut outs
Mounting Option: Castor wheels (Front 2 wheels with Break and rear
without break) Or Levelers or Base plinth
Standard Color: Black or Grey
Static Load: 350 kgs

Configuration for standard Racks is welded frame with 4 pillars of Multi Fold profile welded to top and
bottom panels. 2 Pair Depth rails to additionally support the Enclosure. Removable side panels partially
vented for better air circulation. Openings/Cut outs for field cable entry from Top & Bottom of the Rack.
Vented top cover with fan mounting provision, Front Glass or perforated Metal door with lock and key.
Back Vented, perforated or perforated Dual metal door with lock and key. Free Floor standing Design with
4 No. castor wheels 2 no’s with breaks and 2 no’s without breaks. Levelers or Plinth can be provided on
request.
Technical Data:
Rack Standard: Conforms to DIN 41494 or equivalent standard.
Construction: Welded OR CKD (Knock Down)
Front Door: Hexagonal Perforated Single Door
Rear Door: Hexagonal Perforated Single Door
Basic Frame: Steel
Equipment Mounting: DIN Standard 10mm Sq. Slots / Direct M6 Tap
Mounting Angle: 19″ Mounting angles made of formed steel.
Standard Finish: Powder Coated
Top and Bottom Cover: Welded to Frame, Vented and Field Cable
entry exit cut outs.
Mounting Option: Castor wheels (Front 2 wheels with Break and rear
without break) Or Levelers or Base plinth
Standard Color: Black or Grey
Static Load: 500 kgs

Configuration for standard Racks is welded frame with 4 pillars of Multi Fold profile welded to top and bottom panels. 2 Pair Depth rails to additionally support the Enclosure. Removable side panels partially vented for better air circulation.Openings/Cut outs for field cable entry from Top & Bottom of the Rack. Vented top cover with fan mounting provision,Front Glass or perforated Metal door with lock and key. Back Vented, perforated or perforated Dual metal door with lock and key. Free Floor standing Design with 4 No. castor wheels 2 no’s with breaks and 2 no’s without breaks. Levelers or Plinth can be provided on request.

Technical Data:
Rack Standard: Conforms to DIN 41494 or equivalent standard.
Construction: Welded OR CKD (Knock Down)
Front Door: Lockable Toughened Glass Door,
Rear Door: Vented Steel Dual Door.
Basic Frame: Steel
Equipment Mounting: DIN Standard 10mm Sq. Slots / Direct M6 Tap
Mounting Angle: 19″ Mounting angles made of formed steel.
Standard Finish: Powder Coated
Top and Bottom Cover: Welded to Frame, Vented and Field Cable
entry exit cut outs.
Mounting Option: Castor wheels (Front 2 wheels with Break and rear
without break) Or Levelers or Base plinth
Standard Color: Black or Grey
Static Load: 500 kgs

Product charateristics
*For 24 keystone connectors category 5e, 6 or 6A
*LINKEO C patch panel comes with a rear cable
management system as standard that lets you simply
organize cables, providing a neat and clean installation.
*Pre – position panels for a quick look : you’re able to pre –
position any LINKEO C patch panels in the uprights to get
a global overview of your installation
*Equipped with cable management and label holder as
standard
*Delivered in 100% recycled cardboard packaging, without
plastic film and ready to use

Configuration for standard Racks is welded frame with 4 pillars of Multi Fold profile welded to top and
bottom panels. 2 Pair Depth rails to additionally support the Enclosure. Removable side panels partially
vented for better air circulation. Openings/Cut outs for field cable entry from Top & Bottom of the Rack.
Vented top cover with fan mounting provision, Front Glass or perforated Metal door with lock and key.
Back Vented, perforated or perforated Dual metal door with lock and key. Free Floor standing Design with
4 No. castor wheels 2 nos with breaks and 2 no’s without breaks. Levelers or Plinth can be provided on
request.
Technical Data:
Rack Standard: Conforms to DIN 41494 or equivalent standard.
Construction: Welded OR CKD (Knock Down)
Front Door: Lockable Toughened Glass Door,
Rear Door: Single Vented Steel Door
Basic Frame: Steel
Equipment Mounting: DIN Standard 10mm Sq. Slots / Direct M6 Tap
Mounting Angle: 19″ Mounting angles made of formed steel.
Standard Finish: Powder Coated
Top and Bottom Cover: Welded to Frame, Vented and Field Cable
entry exit cut outs.
Mounting Option: Castor wheels (Front 2 wheels with Break and rear
without break) Or Levelers or Base plinth
Standard Color: Black or Grey
Static Load: 500 kgs
