Description
Specification
| Category | Details |
|---|---|
| Ports | 24x 10/100/1000 Ethernet, 4x 1G SFP Uplinks |
| PoE+ Power Budget | Not Applicable (Fanless Model) |
| Fanless Design | Yes |
| Dimensions (W x D x H) | 17.5 x 9.45 x 1.73 inches |
| Console Ports | 1 x RJ-45 Ethernet, 1 x USB mini-B, 1 x USB-A (Storage/Bluetooth Console) |
Memory & Processor
| Component | Details |
|---|---|
| CPU | ARM v7 800 MHz |
| DRAM | 512 MB |
| Flash Memory | 256 MB |
Performance
| Feature | Value |
|---|---|
| Forwarding Bandwidth | 28 Gbps |
| Switching Bandwidth | 56 Gbps |
| Forwarding Rate (64-byte packets) | 41.67 Mpps |
| Unicast MAC Addresses | 16,000 |
| IPv4 Unicast Direct Routes | 542 |
| IPv4 Unicast Indirect Routes | 256 |
| IPv6 Unicast Direct Routes | 414 |
| IPv6 Unicast Indirect Routes | 128 |
| IPv4/IPv6 Static Routes | 16 (each) |
| IPv4 Multicast Routes / IGMP | 1024 |
| IPv6 Multicast Groups | 1024 |
| IPv4/MAC Security ACEs | 600 |
| IPv6 Security ACEs | 600 |
| Max Active VLANs | 256 |
| Available VLAN IDs | 4094 |
| Max STP Instances | 64 |
| Max SPAN Sessions | 4 |
| MTU (L3 Packet) | 9198 bytes |
| Jumbo Ethernet Frame | 10,240 bytes |
| Dying Gasp Support | Yes |
| MTBF (Data / PoE / Full PoE) | 2,026,793 / 698,220 / 698,220 hours |
Environmental Specifications
| Feature | Value |
|---|---|
| Operating Temp (Sea Level) | -5°C to 50°C |
| Operating Temp (1500m) | -5°C to 45°C |
| Operating Temp (3000m) | -5°C to 40°C |
| Operating Altitude | Up to 10,000 ft (3000 m) |
| Operating Humidity | 5% to 90% at 40°C |
| Storage Temp | -25°C to 70°C (-13°F to 158°F) |
| Storage Altitude | Up to 15,000 ft (4500 m) |
| Storage Humidity | 5% to 95% at 65°C |
Connectors & Interfaces
| Interface Type | Details |
|---|---|
| 10BASE-T Ports | RJ-45, Cat 3/4/5 UTP |
| 100BASE-TX Ports | RJ-45, Cat 5 UTP |
| 1000BASE-T Ports | RJ-45, Cat 5 UTP |
| 1000BASE-T SFP Ports | RJ-45, Cat 5 UTP |
| Indicator LEDs | Per-port: Link, Activity, Disabled; System: Status LED |
| Console Cables Included | CAB-CONSOLE-RJ45 (6 ft), CAB-CONSOLE-USB (6 ft, USB-A to mini-B) |
| Power Supply | External, supplied AC power cord connects to standard AC outlet |
