Description
Specifications
| Category | Specification |
|---|---|
| Interfaces & Ports | |
| GE RJ45/SFP Shared Media Pairs | 2 |
| GE RJ45 Internal Ports | 6 |
| GE RJ45 FortiLink Ports (Default) | 2 |
| USB Ports | 1 × USB 3.0 |
| Console (RJ45) | 1 |
| Wireless Interface | No |
| Internal Storage | None |
| Hardware Security | |
| Trusted Platform Module (TPM) | Yes |
| Bluetooth Low Energy (BLE) | Yes |
| Signed Firmware Hardware Switch | No |
| System Performance (Enterprise Traffic) | |
| IPS Throughput | 1.4 Gbps |
| NGFW Throughput | 1 Gbps |
| Threat Protection Throughput | 900 Mbps |
| Firewall Performance | |
| IPv4 Firewall Throughput (1518 / 512 / 64 byte UDP) | 10 / 10 / 7 Gbps |
| Firewall Latency (64 byte UDP) | 3.23 μs |
| Firewall PPS | 10.5 Mpps |
| Concurrent Sessions (TCP) | 1.5 Million |
| New Sessions/Second (TCP) | 45,000 |
| Firewall Policies | 5000 |
| VPN & SSL | |
| IPsec VPN Throughput (512 byte) | 6.5 Gbps |
| Gateway-to-Gateway IPsec Tunnels | 200 |
| Client-to-Gateway IPsec Tunnels | 2500 |
| SSL-VPN Throughput | 950 Mbps |
| Max SSL-VPN Users (Tunnel Mode) | 200 |
| SSL Inspection | |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 715 Mbps |
| SSL Inspection CPS | 700 |
| SSL Inspection Concurrent Sessions | 100,000 |
| Other Performance Metrics | |
| Application Control Throughput (HTTP 64K) | 1.8 Gbps |
| CAPWAP Throughput (HTTP 64K) | 9 Gbps |
| Virtual Domains (Default / Max) | 10 / 10 |
| Max FortiSwitches Supported | 24 |
| Max FortiAPs (Total / Tunnel Mode) | 96 / 48 |
| Max FortiTokens | 500 |
| High Availability | Active-Active, Active-Passive, Clustering |
| Physical & Environmental | |
| Dimensions (H × W × L, inches) | 1.6 × 8.5 × 7.0 |
| Dimensions (mm) | 40 × 216 × 178 |
| Weight | 2.4 lbs (1.1 kg) |
| Form Factor | Desktop / Wall Mount / Rack Tray |
| Input Rating | 12V DC, 3A (Dual Redundancy Optional) |
| Power Supply | Up to 2 External DC Adapters (1 included), 100–240V AC |
| Max Current | 115VAC/0.4A, 230VAC/0.2A |
| Power Consumption (Avg / Max) | 12.69 W / 15.51 W |
| Heat Dissipation | 52.55 BTU/hr |
| Operating Temp | 32°F to 104°F (0°C to 40°C) |
| Storage Temp | -31°F to 158°F (-35°C to 70°C) |
| Humidity | 10% to 90% non-condensing |
| Noise Level | Fanless, 0 dBA |
| Operating Altitude | Up to 7400 ft (2250 m) |
| Compliance | FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB |
| Certifications | USGv6 / IPv6 |
