Specifications
|
| Model |
CS-H6c-R105-1J5WF |
Camera
|
| Resolution |
3K Resolution |
| Image Sensor |
1/2.7″ Progressive Scan CMOS |
| Shutter Speed |
Self-adaptive shutter |
| Lens |
4mm @ F1.6, viewing angle: 87° (Horizontal), 53° (Vertical), 104° (Diagonal) |
| Lens Mount |
M12 |
| Day & Night |
IR-cut filter with auto-switching |
| DNR |
3D DNR |
| WDR |
Digital WDR |
Compression
|
| Video Compression |
H.264/H.265 |
| Video Bit Rate |
Adaptive bit rate. |
| Image |
| Max. Resolution |
2880 × 1620 |
| Frame Rate |
Self-Adaptive during network transmission |
Network
|
| Smart Alarm |
Motion Detection, Human Shape Detection, Loud Noise Detection, Patrol Mode Detection |
| Wi-Fi Pairing |
AP paring |
| Protocol |
EZVIZ cloud proprietary protocol |
| Interface Protocol |
EZVIZ cloud proprietary protocol |
Interface
|
| Storage |
Micro SD card slot (Max. 512G) |
| Power |
TYPE-C |
| Wired Network |
RJ45 X 1 (10M/100M self-adaptive Ethernet port) |
Wi-Fi
|
| Standard |
IEEE802.11a, 802.11b, 802.11g, 802.11n |
| Frequency Range |
2.4G: 2400~2483.5MHz 5G: 5150MHz-5250MHz |
| Channel Bandwidth |
Supports 20MHz |
| Security |
WPA/WPA2, WPA-PSK/WPA2-PSK |
| Transmission Rate |
11b 11Mbps, 11g 54Mbps, 11nHT20 MCS7, 11a 54Mbps, 11nHT20 MCS7 |
| Output Power(EIRP) |
19 dBm |
| Antenna Gain |
1.9 dBi |
General
|
| Operating Conditions |
-10°C to 45°C (14°F to 113 °F ), Humidity 95% or less (non-condensing) |
| Power Supply |
DC 5V/2A |
| Power Consumption |
8W max |
| IR Range |
MAX. 10 meters(32.81ft) |
| Dimensions |
88mm x 88.2 mm x 119mm (3.46” x 3.47” x 4.69”) |
| Packaging Dimensions |
103mm x 103mm x 168mm (4.06” x 4.06” x 6.61”) |
| Bare Weight |
213 g (0.47 lb) |
In the box
|
| In the box |
– Camera |
| – Power Adapter |
| – Power Cable |
| – Drill Template |
| – Mounting Plate |
| – EZVIZ Screw Kit |
| – Regulatory Information |
| – Quick Start Guide |
