Innex Connect Wireless Conferencing System

Description

Specifications

I/O Interface

• ST100 (Speakerphone): Type C PD + DP ALT

• RX100 (Receiver): HDMI; Type C PD; USB A 3.0

Button

• ST100: Mic on/off, Casting, Volume +/-

• RX100: Language switch

Operating System

• Windows 10 / 11

• macOS 10.8 and later

Product Dimensions

• ST100: 180 x 81 x 32 mm / 7.09 x 3.19 x 1.26 in

• RX100: 102 x 45 x 20 mm / 4.02 x 1.77 x 0.79 in

Product Weights

• ST100: 385 g / 13.58 oz

• RX100: 70 g / 2.47 oz

Package Contents

• Innex Connect (ST100 and RX100)

• 1.5m power cable (Type C-C)

• 1.5m HDMI cable

• 0.3m USB switch cable (Type C-A)

• USB-C to HDMI & USB-A Adapter

• 0.5m USB 3.0 Extension Cable

---

Microphone

• Built-in Microphone: 8 MEMS Microphones for 360-degree pickup

• Pick-up Distance: 4m / 13ft

• Sensitivity: -37 ± 1dB FS @ 1kHz

• Frequency: 20Hz – 8kHz

• Sampling Rate: 48kHz

• Features:

  • Beamforming

  • Automatic Noise Suppression

  • Full Duplex Audio

  • Acoustic Echo Cancellation

  • Automatic Gain Control

---

Speaker

• Output: 4Ω 3W

• Sensitivity: 90dB SPL @ 1kHz ± 3dB @ 0.5m @ 3W

• Signal/Noise Ratio (SNR): 50dB

• Frequency Range: 200Hz – 20kHz

• Max Sound Pressure Level: 95dB SPL @ 0.5m @ 3W

---

Display & Streaming

• Max. Screen Output Resolution: 3840 x 2160 @ 30FPS

• Camera Streaming Resolution: 1920 x 1080 @ 30FPS

• Format Supported: H.264

• Wi-Fi Frequency: 5GHz

• Distance:

  • Screen Casting Only: 8 meters

  • Camera Streaming for BYOM: 5 meters
