Description
| Category | Specification |
|---|---|
| Product Code | CSS106-1G-4P-1S |
| Switch Chip Model | QCA8337 |
| Dimensions | 113 x 139 x 28 mm |
| Operating System | MikroTik SwOS |
| Storage Size | 128 KB |
| Storage Type | FLASH |
| MTBF | Approximately 100,000 hours at 25°C |
| Tested Ambient Temperature | -20°C to 70°C |
| Suggested Price | $55.95 |
Powering
| Category | Specification |
|---|---|
| Number of DC Inputs | 2 (PoE-IN, DC jack) |
| DC Jack Input Voltage | 11-30 V |
| Max Power Consumption | 53 W |
| Max Power Consumption (without attachments) | 5 W |
| Cooling Type | Passive |
| PoE In | Passive PoE |
| PoE In Input Voltage | 11-30 V |
PoE-out
| Category | Specification |
|---|---|
| PoE-out Ports | Ether2-Ether5 |
| PoE Out | Passive PoE |
| Max Out per Port Output (input 18-30 V) | 1 A |
| Max Total Out (A) | 2 A |
Ethernet
| Category | Specification |
|---|---|
| 10/100/1000 Ethernet Ports | 5 |
Fiber
| Category | Specification |
|---|---|
| SFP DDMI | Yes |
| SFP Ports | 1 |
Other
| Category | Specification |
|---|---|
| PCB Temperature Monitor | Yes |
| Voltage Monitor | Yes |
Certification & Approvals
| Category | Specification |
|---|---|
| Certification | CE, EAC, ROHS |
| IP | IP |
