Description
General Specifications
Camera
Imaging sensor: 1/2.5-Inch SONY Low Illumination
8.5MP Sensor
Image Resolution : 4k@30fps, 2k@30fps 1080p@30fps,
720p@30fps, 960x540p@30fps, 640x480p@ 30fps
640x360p@30fps
Video format : YUY2 / MJPEG
Viewing Angle : 128°（D） /120°（H） /82°（V）
TV Distortion : <1%
Minimum Illumination : ≥5Lux
Focal Length : 2.2mm
Focus Type : Fixed focal
Object Distance : 30cm~∞
Digital Zoom : 16x digital zoom
Mechanical Pan Rotation Range : 16°(-8° +8°)
Mechanical Tilt Rotation Range : 10°(-5° +5°)
e-PTZ : Yes (UVC /IR remote control)
Shutter Type : Electronic rolling shutter/Frame
exposure
Adjustable Parameter : Brightness, contrast,
sharpness, white balance, contrast, exposure, gain,
Zoom, Pan ,Tilt
Low-Light Correction : Automatic
Image Processing : 2D / 3D Digital Noise Reduction /
Automatic exposure / automatic white balance
AI Function : AI-Powered Framing / Presenter Tracking
/ Speaker Tracking
Operating System
Compatible System : Windows XP, Windows 7
Windows 8， Windows 10，Android V5.0 Or higher
version OS，MAC OS10.6 or above Linux2.6.24 or above
Chrome OS V29.01547 or above Ubuntu
version 10.04 or above
Hardware Requirements: 2.4 GHz Intel® Core 2 Duo
processor or higher 4 GB RAM or more
USB 2.0 port (USB 3.0 required for 4K)
Audio
Microphone : Built in 6PCS microphone array
Microphone Coverage : 180 degrees audio pickup
Talking Pick up distance range : Full-Duplex
Communication Within a 6m Range, Conference Calls of
High Quality
Microphone Frequency Response : 120 – 16,000 Hz
Audio Sample Rate : 16bit 48kHz
Audio Coding Format : PCM, compatibility UAC1.0
Speaker Bar : 2 speaker element sound bar Adopts
Max SPL : 96±3dB SPL @0dB 1kHz at 1m
Speaker Effective frequency range : 200 – 16,000 Hz
Full Duplex Audio : Yes
Automatic Gain Control : YES
Automatic Echo Cancellation : YES
Automatic Noise Suppression : YES
Interface Port
USB Host Port : Audio, video and HID supported over USB
2.0 and 3.0
USB Interface port : 1xUSB 3.0: Type B, famale
Audio output : 1×3.5mm headphone jack
Power interface : 1×4.0mm DC jack
General Specification
Input Voltage : 5V (USB power supply) /DC Jack DC 5V 2A
Current Consumption : 1.3A (MAX)
Power Consumption : 6.5W (Max)
Operating temperature : -10-45℃ ‘-10°C ~ 40°C
(14°F ~ 104°F)
Storage Temperature : -40°C ~ 60°C (-40°F ~ 140°F)
Material : ABS
Dimension (LXWXH) : 352mm×118.5mm×75.5mm
Net Weight : 860g
Accessories : IR remote control, manual,
USB3.0 cable (2m), AC Adapter
–
Download Product Datasheet
https://www.peoplelinkvc.com/wp-content/uploads/2023/03/PeopleLink-AIO-Alpha.pdf
–
