Description
Product Specifications
Chipset : BT8895B
Bluetooth version : V5.0
Bluetooth Profile : A2DP/AVRCP/HFP/HSP
Audio Codec : AAC/SBC
2.G frequency : 2.4GISM（2.402-2.480GHZ）
Frequency response : 20Hz-20KHz
Signal-to-noise ratio : ≥75dB
Distortion degree : <3%
Bluetooth distance : ≤10M
Driver size : Φ40mm
Bluetooth name : PeopleLink Sonic OE10W
Call current : <32mA14
Music current : <23mA12
Music playing time : 14H
Call time : 10H
Headphone Rated voltage : 5V
Headphone Charge time : 2H
Charging port : Type-c
Operating Mode : Button
Battery Capacity : 602040 – 400mAh
Function : How to Use and Status
Turn on / off : 3S, Press and hold the
“dot“ button on the right headphone for 3S to
turn on / off earphone
Bluetooth pairing : The headphone
automatically enters the Bluetooth pairing state
after power on
Microphone : In-built Unidirectional
microphone for seamless calling
Incoming call : 1click the “dot“ button on right
earphone
End call : During call，1 click the “dot“ button on
right earphone
Reject call : 2S Long press 2 seconds on the
right headphone when calling
Music play/pause : 1click the “dot” button on
right earphone when the music is playing, and
repeat the operation to pause
Volume up : 1click “+” button on right
headphone when the music is playing
Volume down : 1click “-” button on right
headphone when the music is playing
Previous track : 2S Press and hold 2 seconds
on right headphone when the music is playing
Next track : 2S Press and hold 2 seconds on left
headphone when the music is playing
Turn on/off noise reduction : Move the noise
reduction button up to turn on the noise
reduction; move the noise reduction button
down to turn off the noise reduction;
Bluetooth disconnected : Turn off the
headphone
Automatic reconnection : After turning on the
headphone, automatically connects to the
mobile phone
Battery indicator : Support
Low Battery Remind : When the Battery is
lower than 20%, it will remind once a minute
–
