Description
General Specifications
Camera
Image Sensor : 1/2.8”CMOS, 2.14MP
Signal Format (SDI) : 1080P60, 1080P50, 1080P30,
1080P25, 1080I60, 1080I50, 720P60, 720P50
Focal length : 3.9mm-46.8mm
Iris : F1.6-F2.8
Optical Zoom : 12x
Digital Zoom : 12x
Field of View : 72.5°-6.3°
Focus : Auto, Manual, PTZ Push, One Push
Min. Illumination : 0.5 Lux (Color), 0.1 Lux (B/W)
Shutter Speed : 1/25-1/10,000s
AGC : Auto/Manual
White Balance : Auto, Indoor, Outdoor, One
Push Manual, Auto Track
AE Control : Auto, Manual, Shutter Priority, Iris
Priority
S/N : ≥50dB
DNR : 2D/3D
BLC : Support
Pan Range : 90°~+90°
Tilt Range : -30°~+90°
Pan Speed : 0.1°~120°/ s
Tilt Speed : 0.1°~80°/s
Preset Number : 255
OSD : Yes
Image Flip : Yes
Network
Max. Image Size : 1920 × 1080 @60 fps
Video Compression : H.265,H.264
Audio Compression : AAC
Protocol : HTTP, RTSP, RTMP, RTP, TCP, UDP, ONVIF
Dual Stream : Support
Interface
Video Output : 1 × HDMI Interface,1×3G-SDI
Interface
Audio Input : 2 × LINE IN,
including one channel with EC
Audio Output : 1 × LINE OUT
Network Interface : 1 × 10M/100M
USB Interface : 1 × USB2.0
Control Interface : 1 × RS-232
General Specifications
Control Protocol : VISCA, PELCO-P, PELCO-D
Address : 0~63
Power Supply : DC12V
Power Consumption : <50W
Working Temp : 0°C ~ + 40°C
Storage Temp : -20°C ~ +60°C
Dimension (LxWxH) : 500 mm x 162mm x 137mm
Weight : 3kg
–
Download Product Datasheet
https://www.peoplelinkvc.com/wp-content/uploads/2023/03/Speaker-Track-Pro-2024.pdf
–
