Description
Physical Specifications:
| Category | Specification |
|---|---|
| Mounting | Rackmount kit available (to be ordered separately) |
| Dimensions | Width X Height X Depth: 320 x 44 x 212 mm |
| Weight | 2.4 kg / 5.29 lbs (unpacked), 3.9 kg / 8.60 lbs (packed) |
| Power Supply | External auto-ranging AC-DC, 100-240VAC, 2A@50-60 Hz, 12VDC, 5.42A, 65W |
| Optional Power Supply | Optional second redundant power supply |
| Power Consumption | 26.5W / 90.42 BTU/hr (128 idle), 35W / 119.42 BTU/hr (128w max.) |
| Noise Level (avg.) | XGS 128 – 17.3/26.9 dBA, XGS 128w – 19.5/31 dBA |
| Operating Temperature | 0°C to 40°C (operating), -20°C to +70°C (storage) |
| Humidity | 10% to 90%, non-condensing |
| Certifications | CB, CE, UKCA, UL, FCC, ISED, VCCI, KC*, BSMI, RCM, NOM, Anatel*, TEC |
Performance (XGS 128):
| Category | Specification |
|---|---|
| Firewall Throughput | 19,100 Mbps |
| Firewall IMIX | 14,500 Mbps |
| IPS Throughput | 4,650 Mbps |
| Threat Protection Throughput | 4,000 Mbps |
| NGFW Throughput | 4,350 Mbps |
| Concurrent Connections | 6,000,000 |
| New Connections per Second | 72,250 |
| IPsec VPN Throughput | 15,050 Mbps |
| IPsec VPN Concurrent Tunnels | 2,500 |
| SSL VPN Concurrent Tunnels | 1,500 |
| Xstream SSL/TLS Inspection | 1,450 Mbps |
| Xstream SSL/TLS Connections | 18,432 |
Physical Interfaces:
| Category | Specification |
|---|---|
| Storage (local quarantine/logs) | 64 GB UFS 2.1 |
| Ethernet Interfaces (fixed) | 9 x 2.5 GE copper, 1 x SFP fiber |
| Power-over-Ethernet (fixed) | 0 |
| Management Ports | 1 x COM RJ45, 1 x Micro-USB (cable included) |
| Other I/O Ports | 1 x USB 2.0 (front), 1 x USB 3.0 (rear) |
| Number of Expansion Slots | 1 |
| Optional Add-on Connectivity | 5G module (Gen.2) |
