Description
CBS350-24S-4G-EU Specification |
|
| Capacity in millions of packets per second (mpps) (64-byte packets) | 41.66 mpps |
| Switching capacity in gigabits per second (Gbps) | 56.0 Gbps |
| Head-of-Line (HOL) blocking | HOL blocking prevention |
| MAC table | 16K addresses |
| Jumbo frame | Frame sizes up to 9K bytes. The default MTU is 2K bytes |
| Quality of Service (QoS) | 802.1p priority based, 4 hardware queues, priority queuing and Weighted Round-Robin (WRR) |
| Loop detection | Helps discover loops in the network to avoid broadcast storms |
| Cable diagnostics | Quickly identify and troubleshoot network cable faults and/or shorts |
| Media-dependent interface | Automatic Media Dependent Interface (MDI) and MDI crossover (MDI-X) |
| Total system ports | 28 x Gigabit Ethernet |
| RJ-45 ports | 24 x Gigabit SFP Slots |
| Uplink ports | 2 x Gigabit Ethernet combo + 2 SFP |
| LEDs | System, Link/Act, Speed |
| Cabling type | Category 5e or better |
| Mounting options | Desktop, wall-mount or rack mount |
| Physical security lock | Kensington lock slot |
| Flash | 256 MB |
| CPU | 800 MHz ARM |
| DRAM | 512 MB |
| Packet Buffer | 1.5 MB |
| Unit dimensions | 440 x 203 x 44 mm (17.3 x 7.99 x 1.73 in) |
| Unit weight | 2.7 kg (5.95 lb) |
| System power consumption |
110V=32.0W 220V=34.3W |
| Power consumption (with PoE) | N/A |
| Heat dissipation (BTU/hr) | 117.0 |
| Operating temperature | 23° to 122°F (0° to 50°C) |
| Storage temperature | –13° to 158°F (–20° to 70°C) |
| Operating humidity | 10% to 90%, relative, noncondensing |
| Storage humidity | 10% to 90%, relative, noncondensing |
| Mean Time Between Failures (MTBF) | 258,544 hours |
