Description
Detailed Specifications
Camera Specifications
- Image Sensor: 1/2.8″ HD CMOS Sensor
- Effective Pixels: 2.07 Megapixels
- Video Resolution: Full HD 1080P
- Optical Zoom: 20× Optical Zoom
- Digital Zoom: 16× Digital Zoom
- Lens: f=5.5mm ~ 110mm
- Aperture: F1.6 ~ F3.5
- Horizontal Field of View: 60.7° ~ 3.36°
- Vertical Field of View: 34.1° ~ 1.89°
- Minimum Illumination: 0.5 Lux
- Signal-to-Noise Ratio: ≥55dB
- White Balance: Auto / Manual / Indoor / Outdoor / One Push
- Focus Mode: Auto / Manual
- Backlight Compensation: Supported
- Wide Dynamic Range: Supported
- Noise Reduction: 2D & 3D DNR
- Image Flip: Supported
PTZ Specifications
- Pan Rotation Range: ±170°
- Tilt Rotation Range: -30° ~ +90°
- Pan Speed: 1.7° ~ 100°/s
- Tilt Speed: 1.7° ~ 69.9°/s
- Preset Positions: 255
- Preset Accuracy: 0.1°
- PTZ Control Protocols: VISCA / PELCO-D / PELCO-P
Video Output Specifications
- USB Video Output: 1080P30
- HDMI Output: Supported
- LAN Streaming: Supported
- Video Compression: H.264 / H.265 / MJPEG
- Streaming Protocols: RTSP / RTMP / ONVIF
Interface & Connectivity
- USB Interface: USB 2.0
- HDMI Interface: 1 × HDMI
- LAN Port: RJ45 Ethernet
- RS232 Input: Supported
- RS232 Output: Supported
- Audio Input: 3.5mm Line In
Audio Specifications
- Audio Compression: AAC / MP3 / PCM
- Audio Input Support: Supported
- Embedded Audio: Supported
System Compatibility
- Windows: Windows 7 / 8 / 10 / 11
- macOS: Supported
- Linux: Supported
- Video Conferencing Platforms: Zoom, Microsoft Teams, Skype, Google Meet
Physical Specifications
- Power Supply: DC 12V
- Power Consumption: 12W Max
- Operating Temperature: -10°C to 40°C
- Storage Temperature: -40°C to 60°C
- Dimensions: 240 × 145 × 163 mm
- Weight: Approx. 1.4 kg
Product Categories
- PTZ Conference Camera
- Full HD Video Conferencing Camera
- USB PTZ Camera
- 20X Optical Zoom Camera
- Business Conference Camera
- Live Streaming Camera
- Hybrid Meeting Camera
- Professional Video Camera
